and the Diameter of the sphere
-
on which the double convex Object-glass was ground was about 102 Feet;
-
hence I gathered the thickness of the Air
-
or Aereal Interval of the Glasses in that Ring."
-
So in other words, here's the air gap he's trying to measure,
-
which is the sixth ring out. He knows the diameter of that ring.
-
He knows that they touch in the middle, the two glasses,
-
and he knows that it's a sphere
-
and it has a radius of fifty-one feet.
-
So he can just use trigonometry to figure out that the air gap,
-
if he knows that angle there,
-
the air gap is 1.8 microns, right?
